Android App Automatic GSM Gate Opener Switch Remote Access Control Roller Gate Opener
Product Description
RTU5015 GSM Remote Gate/Door Opener:
>>The GSM Gate Opener RTU5015 is a very simple device which can be used for
authorized door access, controlling gates, switching of remote equipments, car parking systems.
>>Actually the GSM Gate Opener RTU5015 can be used in places which require turn ON/OFF
your system, machine, equipment remotely with a FREE call from your mobile phone.
>>2 Digital Input (NC/NO, dry contact) Can use for Water Level Detector, Gas Detector,
Smoke Detector, PIR Motion Detector, Door Magnets Sensor.etc.
>>1 Relay Output (3A/240VAC, NC and NO, Dry Contact) Well used for remotely switch ON/OFF
equipments by Free Charge Phone Call.
How RTU5015 Works?
> 1 Put a SIM Card into the Device.
2Set the Authorize Users(up to 64) phone number to RTU5015 by SMS Text.
3Call the SIM Card Phone Number by Authorized Users, then Relay Switch ON/OFF,
to remote control the Gate/Door or other Machine OPEN/CLOSE!
>>>ALARM and CONTROL FUNCTION:
1Connect wired detector/sensors in tothe INPUT1/2.
2When detector/Sensors TRIGGE RRTU5015 the Alarm SMS Text to User automatically.
3According to the Alarm SMS, users make a decision to CALL RTU5015 Switch Relay ON or OFF.
Specifications:
Parameter item Reference scope
GSM Frequency Dual-Band, GSM900/1800, or GSM850/1900
Digital Input 2, NC/NO, Dry Contact
Relay Output 240VAC/3A,Dry Contact, Switch ON/OFF by Phone Call
Siren Output +12V DC, Wire Siren(*Optional)
Authorized User Up to 64 Phone Numbers (*Customization for more users).
DC Power Supply Standard adapter: DC12V/1A
Power consumption 12V input, Max. 50mA/Average 50mA
SIM Card Supporting 3V SIM Card
GSM Antenna 50 Ω SMA Antenna interface
Temperature Range -20-+60 °C
Humidity range Relative humidity 90% (Condensation Free)
Exterior dimension 110mm*90mm*40mm (W*D*H)
Net Weight 600 g
Packing list:
1 pcs GSM Gate Opener Control Box
1 pcs GSM Magnetic mount Antenna (3 meters length)
(Power adapter DC12V/2A Not included in this order package)
Packing Size: 15*25*10cm
Gross weight: 0.4 kg
Our Services
All our customer service people are fluent in English; they will take good care of your requirements and transfer all the technical drawings and specifications. we can arrange shipment from Shanghai Port or Nantong Port to your designated portor or send directly the goods to customers' warehouse in Shanghai.
It is always our goal to provide satisfactory services to customers with reasonable price, high quality product, accurate delivery time and all necessary assistance. We look forward to hearing from you and growing together with you.
we are in sliding wheel making more than 25 yes a factory.
we are the quality supplier of alibaba for 13 years.
we are running aliexpress at the same time.
The web address is :
https://rongrolling.aliexpress.com/store/613694?spm=2114.search0104.3.82.2567c9c7rDSWTm
well received the following:
1. How to order with "RongRolling" sliding gate parts?
A:"RongRolling" is brand name of sliding gate wheels of Nantong RongChang Manufacture&Trading Co., LTd. When you order us we need you to provide us detailed size. Diameter of wheels or drawings.
You should tell us what kind of grade you need.
On usual we provide new samples need 10working days by OEM item
For 10000pcs we need 20 working days to produce one item
we accept T/T L/C and D/A D/p payment term
2. How to choose right wheels for your gate?
A:Sliding wheels come in several grade.
The highest grade is heat treated C45 steel with dual bearing. This kind wheels is fit for big wheels and special heavy gate.
The rank grade is C45 steel rods turning with one or two bearing. This will suffice for most installations.
Lower grade is by cast iron wheels are not recommended even if cheaper enough.
Now days for the heavy big gate cantilever wheels is very popular for heavy gate . which is use by some pulley block.
If you need quality and quite wheels you can choose a right steel wheels with rubber cover. For light gate you can use good nylon wheels with bearing inside.
3. How about Rongrolling sliding gate wheel?
A:Sliding gate wheels are integral features of your outdoor hardware, and at Barrier Components we sell this products in more than 30 alternative size, Our entire range of sliding gate wheels are galvanized and sold with sealed for life bearing guaranteeing their longevity and performance over a sustained period of time. These products also come equipped with various types of internal support brackets including U and V shaped grooves alongside round grooves.
4. Choose galvanize or stainless steel wheel?
A:On usual the people use galvanized wheels, the galvanized wheel in two grade :96hours salt test and 72 hours which is enough for sun and rain out side, 48 hours not recommend. If you still need higher cover dealing you can use electric paint.
Only when you nearby sea you can choose SS304 or SS316, SS 201 not recommend which is worse than galvanize.
5. Can we buy sliding gate wiheels with Barrier Components?
A:We also sell galvanized wheels with bearings and axle lubrication points and this helps to complete our comprehensive range of sliding gate wheels. All weights quoted are based on each individual wheel, so if you want to buy sliding gate wheels you should contact with our team of experts today to ensure that you make an informed decision.
6. Are you manufactory or trading company?
A: We are manufactory in NANTONG.
7. can we visit your factory?
A:We are warmly welcone you to our factory,10 minutes from Qingtian train stations by car.
8. Can we get samples?
A: We offer free sample.
9. How can we get samples?
A: You offer your name card and pay for the express fee,we will send you in one day.
10. What is your advantage?
A:1.Develop one new design in two year
2.Stock goods send in 7 day,OEM&ODM goods send in 30-45 days
3.Compensation for all problems goods.1. How to order with "RongRolling" sliding gate parts?
